XPS Foam Sheets
1.Premium Thermal Insulation - Delivers R-5.0/inch for superior energy efficiency
2.Complete Moisture Barrier - Impermeable structure prevents water absorption
3.Structural Durability - 45psi compressive strength for heavy-duty applications
4.Easy Workability - Lightweight yet rigid for simple cutting and installation
5.Sustainable Choice - Contains 25-30% recycled content
6.Multi-Surface Application - Compatible with roofs, walls, floors and backer boards
Product Introduction:
XPS foam sheets are high-performance insulation panels featuring a dense closed-cell structure. These rigid boards provide exceptional thermal resistance when used with backer board systems, while offering excellent moisture protection and dimensional stability. The material maintains consistent performance in extreme temperatures (-60°C to +80°C), making it ideal for both residential and commercial construction projects.
Product Parameters:
Core Material： | |
Standard Thickness： | 25mm-100mm |
Thermal Resistance： | R-5.0 per inch |
Compression Rating： | 45psi (310kPa) |
Water Vapor Diffusion： | <0.03 perm |
Fire Classification： | Class B1 |
Panel Size Options： | 600x1200mm, 1200x2400mm |
Service Life： | 50+ years |
Product Application:
